| model | HW-TDX-2000GL |
| Drilling ability | |
| caliber | HTW-NTW-BTW |
| depth | 1000-2000-2500(M) |
| Hydraulic system | |
| preset pressure | 28(MPA) |
| Rated flow | 380(L/nin) |
| Cooling type | Air cooling + Water cooling |
| Engine | |
| Brand | Yuchai |
| Type | Turbocharged |
| Rated rotary speed | 2400(RPM) |
| Rated power | 162（KW） |
| Power head | |
| Maximum torque | 1000-4000(N.M) |
| Maximum rotary speed | 1300(RPM) |
| Feeding stroke | 3500(MM) |
| Drilling tower | |
| Type | Ground contact integrated tower |
| Drilling angle | 45-90(°) |
| Lifting force | 22(T) |
| Feeding force | 11(T) |
| Winch | |
| Lifting force | 1500(KG) |
| Rotary speed | 100-300(RPM) |
| Wire rope diameter | 6(MM) |
| Rope capacity | 2000(M) |
| walk | |
| type | Manual + remote control |
| Walking speed | 3.5(KM/H) |
| Single machine climbing angle | 45(°) |
| hydraulic mud pump | |
| mud pump | Contains Bw-320 mud pump |
| flow | 0-320(L/in) |
| pressure | 0-10(MPA) |
| Shipping dimensions | 6300*2200*2700(MM) |
| Total Weight | 12.7(T) |
Hengwang Group aims to provide you with complete engineering equipment solutions to reduce your costs and increase your profits.
Fill in the form to get the latest product parameters and the lowest price.
